Brand: FERRTX
| Selling Units: | Piece/Pieces |
|---|---|
| Download: |
|
±1% Accuracy with 5kV Isolation for Industrial Drives
The FERRTX HKC Series Closed Loop Hall Effect Current Sensor delivers laboratory-grade accuracy in harsh environments. Leveraging magnetic compensation technology, it achieves ±1% linearity across DC-10kHz bandwidth – outperforming traditional DC Current Sensors in dynamic response. With reinforced 5kV galvanic isolation and -40°C to +125°C operation, it replaces bulky lem split core current sensor solutions in space-constrained applications.
Zero Magnetic Hysteresis
Eliminates calibration drift vs. open-loop hall effect current sensors
Sub-μs Response Time
5× faster than Rogowski Current Sensors for overcurrent protection
Wide Voltage Compatibility
4.5-24V supply range (TTL/CMOS compatible)
EMC Immunity
Withstands 100V/ns dv/dt noise in VFD environments
▸ Bandwidth: DC–10kHz (captures motor drive transients)
▸ Accuracy: ±1% @25°C (±1.8% -40°C to +125°C)
▸ Isolation: 5kV RMS/60s (IEC 62368-1 certified)
▸ Response Time: <0.5μs
▸ Current Ranges: 50A, 100A, 200A, 500A
Industrial Automation
・Servo motor phase monitoring (±0.8% repeatability)
・PLC analog input modules
・Welding equipment current control
Energy Infrastructure
・Solar inverter MPPT tracking
・BESS discharge control
・Wind turbine converter protection
Electric Vehicles
・Traction inverter current sensing
・OBC leakage detection
・BMS high-voltage isolation
Consumer Electronics
・UPS inrush limiting
・Server PDU monitoring
・Industrial SMPS feedback
| Product Series | IDC(A) | Supply Voltage(V) |
| 05-HKC-EKB1 | 200-4000 | 15 |
| 20-HKC-B | 50-300 | 12-18 |
| HKC-2012Y1 | 2000-10000 | 12-15 |
| HKC-B1 | 50-600 | 12-15 |
| HKC-BS | 50-600 | 15 |
| HKC-BS5-0.626 | 50-600 | 5 |
| HKC-BS5 | 50-900 | 2.5 |
| HKC-BT | 50-600 | 15 |
| HKC-E | 50-500 | 12-15 |
| HKC-EKA | 100-500 | 15 |
| HKC-EKAD1 | 30-600 | 15 |
| HKC-EKAS12 | 100-500 | 12 |
| HKC-EKASDA-2012 | 20 | 24 |
| HKC-EKASY-2012 | 50-500 | 24 |
| HKC-EKB | 200-2000 | 15 |
| HKC-EKBS12 | 200-2000 | 12 |
| HKC-FK | 200-1000 | 15 |
| HKC-H | 600-3000 | 15 |
| HKC-HA | 800-5000 | 12-15 |
| HKC-HAHS52 | 50-1500 | 5 |
| HKC-HAS | 50-600 | 15 |
| HKC-HASP | 50-600 | 15 |
| HKC-HAT | 100-2000 | 15 |
| HKC-HAX-2019 | 500-2500 | 15 |
| HKC-HB-2019 | 1000-12000 | 15 |
| HKC-HOP | 800-3000 | 15 |
| HKC-K | 400-2000 | 15 |
| HKC-KB-2019 | 800-3000 | 15 |
| HKC-KB | 500-5000 | 12-15 |
| HKC-KC | 1000-10000 | 15 |
| HKC-LBP | 200 | 15 |
| HKC-LBS5 | 50-450 | 24 |
| HKC-LTH | 10-450 | 15 |
| HKC-N | 50-1000 | 15 |
| HKC-PTPS | 50-150 | 5 |
| HKC1000SML | 1000 | 15 |
| HKC18P-D1 | 40-60 | 15 |
| HKC18P-D15 | 40-60 | 15 |
| HKC18P03-50D15 | 3-50 | 15 |
| HKC2000F | 200-2000 | 12-15 |
| HKC2000H | 600-3000 | 12-15 |
| HKC2000K | 400-2000 | 12-15 |
| HKC200LBP-4V | 200 | 15 |
| HKC2105-20 | 50-500 | 12-15 |
| HKC4000KB-170316 | 500-4000 | 12-15 |
| HKC5000HOP-180108 | 2000-5000 | 15 |
