Brand: FERRTX
| Selling Units: | Piece/Pieces |
|---|---|
| Download: |
|
Place of Origin: China
Certificate: RoHS
Series in this family
| Product Series | Inductance(µH) | IDC(A) | Length (mm) | Width (mm) | Height (mm) |
| LPM Series | 0.1-100 | 2.75-45 | 4.06-6.6 | 4.45-7.2 | 2.0-8.0 |
| LPM13 Series | 0.1-47 | 2.5-60 | 14.2 | 13 | 4.0-6.2 |
| LPM15XX Series | 4.7-33 | 13-31 | 17.5 | 16.5 | 9.7-12.7 |
| LPM0110 | 0.22-10 | 0.32-1.7 | 1.2 | 1.0 | 0.8 |
| LPM0420C | 0.1-10 | 1.8-18 | 4.5 | 4.5 | 2.0 |
| LPM0515C | 0.15-10 | 2.3-16 | 5.5 | 5.5 | 1.5 |
| LPM0518C | 0.22-4.7 | 3.5-16 | 5.5 | 5.5 | 1.8 |
| LPM0520C | 0.1-10 | 2.0-20 | 5.5 | 5.5 | 2.0 |
| LPM0530C | 0.1-33 | 2.0-23 | 5.5 | 5.5 | 3.0 |
| LPM0620C | 0.1-10 | 3.0-21 | 7.4 | 7.4 | 2.0 |
| LPM0624C | 0.1-15 | 3.5-30 | 7.4 | 7.4 | 2.4 |
| LPM0630C | 1.0-22 | 4.0-40 | 7.4 | 7.4 | 4.0 |
| LPM0640C | 0.15-12 | 4.0-40 | 7.4 | 7.4 | 4.0 |
| LPM0650C | 0.47-47 | 2.5-22 | 7.6 | 7.6 | 5.0 |
| LPM0830C | 0.22-33 | 3.0-30 | 9.2 | 9.2 | 3.0 |
| LPM0840C | 0.22-47 | 3.0-32 | 9.2 | 9.2 | 4.0 |
| LPM0850C | 0.15-22 | 5.0-45 | 9.2 | 9.2 | 5.0 |
| LPM1020C | 0.33-2.2 | 8-29 | 10.5 | 10.5 | 2.0 |
| LPM1030C | 0.36-6.8 | 7.0-25 | 10.5 | 10.5 | 3.0 |
| LPM1040C | 0.19-47 | 3.6-40 | 10.5 | 10.5 | 4.0 |
| LPM1050C | 0.36-22 | 6.0-33 | 10.5 | 10.5 | 5.0 |
| LPM1050D | 3.3-22 | 2.5-7.0 | 10.2 | 10.2 | 5.0 |
| LPM1060C | 1.0-4.7 | 14-26.5 | 11.3 | 10.0 | 6.0 |
| LPM1080D | 8.2-22 | 4.0-6.0 | 11.2 | 11.2 | 8.0 |
| LPM1090D | 1.0-47 | 2.3-17 | 10.2 | 10.2 | 9.0 |
| LPM1213D | 8.2-22 | 5.5-10 | 13.8 | 13.8 | 13 |
| LPM1235C | 0.1-10.0 | 7.0-48 | 13.2 | 13.2 | 3.5 |
| LPM1250C | 0.1-22 | 7.0-50 | 13.2 | 13.2 | 5.0 |
| LPM1260C | 0.33-10.0 | 11-45 | 13.2 | 13.2 | 6.0 |
| LPM1265C | 0.15-68 | 5.0-60 | 13.2 | 13.2 | 6.5 |
| LPM1280C | 1.0-2.2 | 26-35 | 13.2 | 13.2 | 8.0 |
| LPM1770C | 1.0-350 | 3.0-50 | 18 | 18 | 7.0 |
| LPM2010C | 0.24-2.2 | 1.6-6.3 | 2.0 | 1.6 | 1.0 |
| LPM2213C | 0.47-400 | 4.0-80 | 22.5 | 22.5 | 13 |
| LPM2510C | 1.0-4.7 | 1.5-3.5 | 2.5 | 2.0 | 1.0 |
| LPM2512C | 0.22-4.7 | 1.8-8.0 | 2.5 | 2.0 | 1.2 |
| LPM3210C | 1.0 | 4.0 | 3.2 | 2.5 | 1.0 |
| LPM3212C | 4.7 | 2.0 | 3.2 | 2.5 | 1.2 |
| LPM3215C | 0.22 | 11 | 3.2 | 2.5 | 1.5 |
| LPM3220C | 1.0-4.7 | 2.8-5.4 | 3.2 | 2.5 | 2.0 |
| LPM4010C | 1.0-10.0 | 1.5-3.5 | 4.0 | 4.0 | 1.0 |
| LPM4012C | 0.25-10.0 | 1.8-8.0 | 4.0 | 4.0 | 1.2 |
| LPM4015C | 0.47-2.2 | 6.0-9.2 | 4.0 | 4.0 | 1.5 |
| LPM4020C | 0.33-22 | 1.7-13 | 4.0 | 4.0 | 2.0 |
| LPM4030C | 0.15-10.0 | 3.1-24 | 4.0 | 4.0 | 3.0 |
| LPM4040C | 0.15-10.0 | 2.8-21 | 4.0 | 4.0 | 4.0 |
| LPM5020C | 0.15-6.8 | 4.5-27 | 5.4 | 5.2 | 2.0 |
| LPM5030C | 0.15-10.0 | 4.5-30 | 5.4 | 5.2 | 3.0 |
| LPM6030C | 0.15-10.0 | 7.0-35 | 6.6 | 6.4 | 3.0 |
| LPM6060C | 0.22-15 | 7.4-29 | 6.6 | 6.4 | 6.0 |
| LPM10100C | 1.0-15 | 13.8-43.5 | 11.3 | 8.0 | 10.0 |
| LPM1707 | 0.22-22.0 | 11-80 | 17.15 | 17.15 | 7.0 |
