SMD Inductor SMB

Product Overview

The SMB Series SMD Inductor delivers exceptional power handling in compact surface-mount packages, designed for applications requiring ultra-high currents up to 65A. These shielded ferrite-core components outperform conventional Power Inductor solutions with 40% lower DCR and superior thermal management. Their robust construction ensures stable performance across extreme temperatures (-55°C to +130°C), making them ideal for space-constrained power designs.

Key Specifications

• Ultra-High Current Capacity: Up to 65A saturation current (Isat) and 30A Irms with DCR as low as 0.8mΩ.

• Wide Inductance Range: 300nH to 1.6μH (±10-15% tolerance) for versatile circuit design.

• Compact Footprints: Miniature sizes from 3.1×2.5mm to 10×10mm with optimized thermal pads.

• Enhanced Thermal Resilience: Operates from -55°C to +130°C (SMB1007B) with only 40°C temperature rise at rated current.

• High-Frequency Performance: Suitable for applications up to 100MHz, outperforming many RF Inductor components in power density.

Technical Advantages

Unlike traditional Transformers, these SMD Inductor solutions feature:

1. Shielded construction reducing EMI radiation by 30% vs. unshielded alternatives.

2. Ferrite cores minimizing losses in Power Converter systems operating at 5MHz.

3. 50% higher current density than standard Power Inductor designs.
   For EMI-sensitive applications, pair with our EMC Filter products to achieve full CE/FCC/VCCI compliance.

Typical Applications

1. Server/GPU Power Systems: Vcore regulators and multi-phase VRMs handling 28A+ continuous current.

2. Automotive Electronics: ADAS Sensor arrays and battery management systems (BMS).

3. Industrial Equipment: Motor drives and Sensor interfaces requiring -55°C operation.

4. Consumer Electronics: High-current laptop adapters and 4K TV power boards.

5. Renewable Energy: Solar micro-inverters and Power Converter stages.

Performance & Reliability

• Current Handling: Isat rated at 20% inductance roll-off (verified @100kHz/1Vrms).

• Thermal Management: Optimized pad layouts dissipate heat 25% faster than standard designs.

• Quality Validation: 100% automated testing with HP4284A LCR meters and thermal imaging.

• Compliance: RoHS/HF compliant, MSL Level 1 moisture sensitivity.

Why Choose SMB Series?

• Space Efficiency: 10mm max height enables stacking in high-density Power Converter designs.

• Vibration Resistance: Critical for automotive Sensor modules exposed to mechanical stress.

• Scalable Solutions: Tape-and-reel packaging (400-500pcs/reel) for automated assembly.

Series in this family
