PCB Mount Flyback Transformers

PCB Mount Flyback Transformers are widely used in isolated switch-mode power supplies where compact size, efficiency, and electrical safety are essential. Designed for direct PCB installation, these transformers support flyback topologies commonly found in low- to medium-power conversion systems.

As part of Ferrtx’s Flyback Transformers Power Transformers portfolio, this product family is optimized for high-frequency operation and modern power electronics.

What Is a PCB Flyback Transformer?

A PCB Flyback Transformer is a high-frequency magnetic component used in flyback power supply circuits. Unlike current transformers, flyback transformers store energy in the magnetic core during the switch-on period and release it to the secondary side during switch-off.

This energy-transfer mechanism makes flyback transformers ideal for:

• Isolated AC-DC power supplies

• DC-DC converters

• Auxiliary power modules

They belong to the broader Transformer category while being optimized for switching applications.

Key Features of PCB Mount Flyback Transformers

Ferrtx PCB mount flyback transformers are designed to meet the electrical and mechanical demands of high-density power designs.

Key advantages include:

• Optimized for high switching frequencies

• PCB mount structure for easy assembly

• Stable isolation performance

• Compact footprint for space-saving layouts

• Consistent electrical characteristics across production batches

These characteristics make them a reliable High Frequency Transformer solution for power electronics.

Flyback Transformers in Power Converter Applications

Flyback transformers are a core component in many Power Converter systems, especially where isolation and cost efficiency are required.

Typical power converter applications include:

• AC-DC adapters

• Industrial control power modules

• Embedded power supplies

• Communication and networking equipment

Their ability to combine voltage transformation and isolation in a single magnetic component makes flyback transformers highly versatile.

Custom Flyback Transformer Solutions

Ferrtx provides custom PCB mount flyback transformer solutions based on customer requirements, including:

• Input and output voltage configuration

• Power rating optimization

• Insulation and safety standards compliance

• Core material and winding customization

Our engineering team supports both standard designs and customized flyback transformers for volume production.

Why Choose FERRTX PCB Flyback Transformers?

• Clear focus on flyback power transformer applications

• High-frequency design expertise

• Stable quality and reliable supply

• Technical support from prototype to mass production

FERRTX PCB mount flyback transformers deliver efficient and dependable performance for modern power conversion systems.
