High Efficiency CCFL Transformer Design

CCFL Transformers are essential components used in compact inverter circuits to generate the high voltage required to drive cold cathode fluorescent lamps (CCFLs). At Ferrtx, we specialize in producing reliable, precision-engineered transformers optimized for display backlighting, industrial instrumentation, and other low-power illumination systems.

Our CCFL Transformer range is engineered with optimized winding structures and magnetic materials to deliver stable output, long service life, and high energy efficiency—making them ideal replacements or upgrades in modern CCFL inverter transformer designs.

Optimized for Modern CCFL Transformer Design

Ferrtx develops its CCFL transformer series with performance consistency and compact form factor in mind. Whether you're upgrading an existing design or building a new CCFL transformer design for LCD displays, scanners, medical monitors, or industrial lighting, our transformers offer:

Key Features

• High Output Voltage
  Stable and efficient performance for single-lamp and dual-lamp inverter circuits.

• Compact & Lightweight Structure
  Ideal for slim and portable applications such as handheld devices and thin-profile displays.

• Excellent Start-Up Characteristics
  Ensures reliable ignition even under low-temperature environments.

• Low Power Consumption
  Supports energy-efficient systems while extending lamp lifespan.

• Customized Solutions Available
  OEM and ODM support for PCB footprint, winding configuration, voltage ratio, and connection style.

Applications

Our CCFL Transformers are widely used in:

• LCD monitor and TV backlighting

• Instrumentation and control panel displays

• Medical screens and inspection equipment

• Portable electronic devices

• Industrial illumination circuits

• Scanners and measurement systems

Why Choose Ferrtx CCFL Transformers?

1. Professional High-Frequency Magnetic Expertise
Our CCFL series leverages the same engineering capabilities used in our advanced High Frequency Transformer product line, ensuring stability, reduced core loss, and long-term reliability.

2. Better Compatibility in Power Conversion Systems
Designed for smooth integration into various Power Converter architectures used in CCFL inverter applications.

3. Quality & Durability You Can Trust
As a professional Electronic Transformer manufacturer, we apply rigorous testing to guarantee performance under diverse operating conditions.

Customization Options

We support a wide range of OEM customization:

• Input & output voltage configuration

• Turns ratio

• Operating frequency

• Core material selection

• Mounting structure (SMD / Through-hole)

• Single-lamp / dual-lamp inverter support

If you require tailored CCFL inverter transformer solutions for special lighting modules, industrial displays, or low-power backlight systems, our engineering team will assist you with full technical support.

Request a Quote

Looking for high-stability CCFL Transformers or need help with CCFL transformer design integration?
Contact FERRTX today for samples, pricing, and technical support.
