D-SUB Filter Connectors

Key Features

• ‌Filter Integration‌: Built-in filters reduce electromagnetic interference (EMI) and radio-frequency interference (RFI), ensuring clean and stable signals.
• ‌Versatile Compatibility‌: Suitable for various ‌rf microwave Components‌, including ‌Power Inductor‌, ‌RF Inductor‌, ‌Transformer‌, and ‌EMC Filters - EMI/RFI‌.
• ‌Robust Design‌: Constructed from high-quality materials for durability and reliability, withstanding harsh environmental conditions.
• ‌Low Insertion Loss‌: Minimizes signal loss, maintaining high signal fidelity over long distances.
• ‌Customizable Options‌: Available in various configurations to meet specific application requirements.

Applications

• ‌Telecommunications‌: Ideal for enhancing the performance of communication networks, improving signal quality and reducing noise.
• ‌Industrial Controls‌: Suitable for industrial automation systems, ensuring reliable signal transmission in noisy environments.
• ‌Test and Measurement Equipment‌: Provides accurate and stable signals for precise testing and measurement tasks.

Series in this family

Product Series	DSF622-019	DSF701-015	DSF701L-015	DSF716-005
	DSF722-005

Gender	Plug / Socket
Orientation	Straight / Right Angle
Housing Material	Plastic / Steel / Zinc / Metal
Contact Body Material	Brass / Phosphor Bronze
Number of Pins	A=15 Pin / B=25 Pin / C=37 Pin / D=50 Pin / E=9 Pin
Operating Temperature	-55℃~125℃
Voltage Rating	300V AC/ RMS 50Hz
Withstanding Voltage	1000V AC/ RMS 50Hz for One Minute
Insulation Resistance	1000MΩ at 500V DC
Contact Resistance	20 MΩ Max.
Single Contact Insertion Force	1.19 lb. (0.54 kg.) Max.
Single Contact Withdrawal Force	0.13 lb. (0.06 kg.) Min.

Benefits of Using Our D-SUB Filter Connector

• ‌Improved Signal Integrity‌: The built-in filters effectively block unwanted noise, resulting in clearer and more reliable signals.
• ‌Seamless Integration‌: Easily integrates with existing ‌RF Microwave Components‌, simplifying system design and implementation.
• ‌Cost-Effective Solution‌: Provides superior performance at a competitive price, reducing overall system costs.

Enhancing Your RF Systems

Upgrade your ‌RF Microwave Components‌ systems with our ‌D-SUB Filter Connector‌. By integrating advanced filtering technology, these connectors ensure optimal signal quality, reducing noise and interference. Whether you're working on a telecommunications network, industrial control system, or test and measurement equipment, our D-SUB Filter Connectors deliver the performance you need.



Ferrtx is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our D-SUB Filter Connectors products.
