Product Description

High Current Power Inductors,SMD Power Inductors‌

The ‌High Quality SMD Inductor HCB‌ leverages advanced ‌Magnetic Cores‌ technology to deliver exceptional performance in high-demand applications. Featuring a ‌Ferrite Core‌ material with ultra-low core loss and high current capacity (14A–35A), this inductor is engineered for stability across extreme temperatures (-40℃ to +125℃). Its compact design and inductance range (22nH–120nH) make it ideal for modern electronics, while the ‌Ferrite Core‌ ensures minimal energy dissipation in ‌Servo ferrite tile absorber‌ systems and ‌ferrite plate material‌-based voltage regulators.

‌Key Features‌

‌High Current & Low Loss‌:
- ‌Magnetic Cores‌ with ‌Ferrite Core‌ material optimize current handling (up to 35A) while reducing thermal stress.
‌Wide Applications‌:
- Compatible with ‌Servo ferrite tile absorber‌ setups in servers and ‌ferrite plate material‌-enhanced VRMs.
‌Robust Temperature Resilience‌:
- Stable operation from -40℃ to +125℃, critical for ‌ferrite plate material‌ durability in portable electronics and data systems.

‌Applications‌

‌Servers/Workstations‌:
- Integrates with ‌Servo ferrite tile absorber‌ modules to suppress EMI in multi-phase regulators.
‌Battery/Graphics Systems‌:
- ‌Ferrite Core‌ efficiency supports high-current graphics cards and battery power management.
‌Voltage Regulator Modules (VRMs)‌:
- ‌Magnetic Cores‌ ensure reliable inductance (22nH–120nH) for precision voltage regulation.
‌Data Networking‌:
- ‌Ferrite plate material‌ minimizes core loss in high-frequency data storage systems.

Series in this family

Product Series	Inductance(µH)	IDC(A)	Length (mm)	Width (mm)	Height (mm)
HCB0404 0505	22-100	19-30	4.0-5.0	4.0-5.0	3.0-4.8
HCB0703	80-150	13-27	7.35	6.6	3.1
HCB0705	72-226	16-43	7.0	7.0	4.95
HCB0805	32-200	16-65	7.62	7.62	4.96
HCB0906	100-300	27.5-51	9.6	6.4	8.0
HCB1005	80-220	26-53	10.2	7.0	4.95
HCB1007	115-470	19-61	10.5	8.0	7.0
HCB1008	120-220	47-68	10.2	8.0	8.0
HCB1107	120-510	14.5-55	11.2	7.2	7.2-7.5
HCB1208	150-250	44-50	11.8	8.1	8.0
HCB1211	230-540	26-40	11.7	11.5	9.2
HCB1313	220-500	28-40	13.46-13.5	13.0-13.2	5.3-8.0
HCB1413	300-680	24-45	14.5	13.3	9.5
HCB040404R32	55-100	17-19	4.0	4.0	4.0
HCB070705R32	100-180	28-50	7.0	6.8	-
HCB100612R125	70-330	40-77	12.0	10.0	6.0
HCB100709R18	100-400	30-70	10.0	7.0	9.0
HCB100808AR18	120-400	26-70	10.0	8.0	8.0
HCB100808R18	100-320	45-74	10.6	8.0	-
HCB100875R29	100-370	30-56	10.2	8.0	7.5
HCB121109R30	150-500	32-55	11.5	11.0	9.0

Ferrtx is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in ourSMD Inductor HCB products.
