Leaded Inductor

Description

Product Attributes

Brand: FERRTX

Packaging & Delivery

Selling Units:	Pound
Download:

Product Description

Are Inductors Used In Dc Circuits

The ‌Leaded Inductor LCHB‌ series represents a premium solution for high-performance electronic circuits, featuring advanced ‌Power Inductor‌ technology. These components are engineered to deliver exceptional performance in ‌RF Microwave Components‌ applications while maintaining compact dimensions and reliable operation.

Key Features
- ‌Precision Manufacturing‌: Crafted with high-quality materials for consistent ‌Leaded Inductor‌ performance
- ‌Wide Inductance Range‌: Suitable for various ‌Power Inductor‌ applications
- ‌Low Core Loss‌: Minimizes energy dissipation in high-frequency operations
- ‌Thermal Stability‌: Maintains consistent characteristics across temperature variations
- ‌Robust Construction‌: Features durable leads for reliable connections
Applications
- ‌Power Conversion‌: Essential component in ‌Transformers‌ designs
- ‌RF Circuits‌: Critical for ‌RF Inductor‌ applications
- ‌EMI Suppression‌: Works effectively with ‌EMC Filter - EMI/RFI‌ solutions
- ‌Sensor Systems‌: Provides stable operation for precision ‌Sensor‌ interfaces
Technical Advantages

The ‌Leaded Inductor LCHB‌ offers:
- High current handling capacity
- Excellent self-resonance characteristics
- Compact footprint for space-constrained designs
- Consistent performance matching datasheet specifications
Performance Benefits

When integrated with other ‌RF Microwave Components‌, the ‌Leaded Inductor LCHB‌ demonstrates:
- Minimal signal distortion in high-frequency applications
- Reliable operation under varying load conditions
- Long-term stability in harsh environments
- Excellent compatibility with various circuit designs
Integration Guidance

For optimal performance with ‌Leaded Inductor LCHB‌:
1. Consider thermal management requirements
2. Pair with appropriate ‌Power Inductor‌ solutions
3. Follow recommended PCB layout practices
4. Verify compatibility with system-level ‌RF Microwave Components‌
Quality Assurance

Each ‌Leaded Inductor LCHB‌ undergoes rigorous testing including:
- Inductance value verification
- DC resistance measurements
- Thermal cycling tests
- Mechanical durability evaluations

Series in this family

Product Series	L(µH)	DCR(Ω)	IDC (mA)
LCHB0406	1.0-25000	0.035-180	20-2000
LCHB0608	3.3-150000	0.016-520	16-3500
LCHB0707	1.0-1500	0.006-5.0	160-5000
LCHB0806	22-1000	0.11-4.45	190-1270
LCHB0807	2.2-1500	0.011-3.5	180-4000
LCHB0810	3.3-100000	0.012-180	28-5000
LCHB0912	10-1000	0.027-2.1	450-4500
LCHB1010	3.3-15000	0.01-24	120-5900
LCHB1012	10-1000	0.022-1.7	560-5300
LCHB1016	10-47000	0.031-56	95-5000
LCHB1018	4.7-100000	0.008-89.7	60-6000
LCHB1213	10-10000	0.023-10	240-5100
LCHB1415	10-47000	0.015-27	150-5000

Ferrtx is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our Leaded Inductor LCHB products.
