Molded RF Inductor: High-Q Axial Lead Inductor for Superior EMI Filtering Performance

Introduction

In the demanding world of electronics, where RF stability, power integrity, and resilience in harsh environments are paramount, off-the-shelf surface-mount components often reach their limits. Our company specializes in engineering high-performance, reliable inductive solutions that thrive where others falter. Our LTM Series Molded RF Inductors stand out with their unique combination of axial lead design, robust molded construction, and precision wire-wound craftsmanship. Designed for excellence in RF applications and effective EMI filtering, these inductors offer superior power handling, enhanced temperature stability, and exceptional reliability for industrial, automotive, and high-frequency circuits. Discover how our components can provide the durability and performance your critical designs demand.

Product Overview: LTM Series molded inductors

The LTM Series represents a class of high-quality axial lead inductors built for durability and stable performance. Encased in molded polypropylene, these wire-wound inductors are engineered to withstand challenging operating conditions while maintaining precise electrical characteristics. They are ideal for applications requiring high Q factors, excellent stability over frequency, and robust construction.

• Core Construction: The LTM0409 series utilizes a phenolic core for values up to 4.7 µH and an iron core for higher inductances, ensuring optimal performance across its range. The LTM0511 series features a thermoset plastic core for values up to 0.68 µH and a Ferrite Core above that.
• Operating Temperature: The series operates reliably within an ambient temperature range of -55°C to +85°C
• Tolerance: Precision tolerances are offered, including J (±5%), K (±10%), and M (±20%).

Key Features and Benefits

1. Robust Molded Construction: The molded polypropylene body provides exceptional mechanical strength, moisture resistance, and protection against environmental factors, making these power inductors suitable for auto otive and industrial applications where reliability is non-negotiable.
2. Axial Lead Design: The axial lead configuration facilitates easy through-hole PCB mounting, offering strong mechanical bonds and superior heat dissipation compared to many SMD alternatives, which is crucial for higher current applications.
3. High-Q Wire-Wound Design: Precision wire-wound construction using specialized techniques ensures high Q (Quality Factor) values, minimizing energy loss at target RF frequencies. This results in efficient operation in resonant circuits and filters.
4. Effective EMI Suppression: These inductors are exceptionally effective as EMI Filter components. Their design helps suppress electromagnetic interference in power lines and signal paths, contributing to cleaner power delivery and improved system compliance.
5. High Voltage and Current Handling: Engineered with special winding wire and coatings, certain variants in the series are designed to operate at elevated voltage levels (e.g., up to 400V models available elsewhere illustrate the capability of axial designs) and handle substantial currents, making them versatile power inductors for various circuits.

Technical Specifications
Below is a summary of key electrical characteristics for select models from the LTM0409 and LTM0511 series:

Note: Specifications are representative. Please refer to the complete datasheet for exhaustive details.

• RF Circuits: Tuners, amplifiers, oscillators, and impedance matching networks benefiting from high Q.
• EMI Filtering: Power supply input filters, noise suppression in data lines, and EMI filter chokes in motor drives and switching power supplies.
• Automotive Electronics: Engine control units (ECUs), lighting systems, and sensors where durability and temperature stability are key.
• Industrial Electronics: Power supplies, industrial controls, and filtering in harsh environments.
• Consumer Electronics: Power management and noise filtering in audio/video equipment.

Why Choose Our Molded RF Inductors?

In a market increasingly dominated by surface-mount components, our axial lead inductors offer a compelling alternative for designs that prioritize proven reliability, superior power handling, ease of prototyping, and performance in demanding conditions. Their molded body ensures longevity, while the wire-wound construction guarantees precise electrical characteristics. Whether you're designing a critical EMI filter, a high-frequency circuit, or a system that must endure harsh environments, our LTM series provides a robust and high-performance solution.

Explore our full range of Molded Inductors today and find the perfect component to enhance your design's reliability and performance!
